XJ-500Z Coaxial Helicopetor
XJ-15 Electric VTOL UAV
Retail price
0.0
元
Market price
0.0
元
Number of views:
1000
Product serial number
Category
Product Center
Quantity
-
+
Stock:
0
1
Product Description
[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[产品参数, 参数]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]
|
Max takeoff weight |
15KG |
|
Wingspan |
2650mm |
|
Length |
1580mm |
|
Max payload |
3KG |
|
Power form |
Electric |
|
Max flight time |
Without payload 3.8H; with camera 3H |
|
Crusing speed |
18-25m/s |
|
Max descent speed |
16m/s |
|
Max flight speed |
35m/s |
|
Max flight distance |
260KM |
|
Operating temperature |
-20℃-+45℃ |
|
Battery |
12S 30000mah |
|
Min Spiral radius |
150m@20m/s |
|
Max flight height |
<5000m |
|
Max allowable wind speed |
Force 5 wind |
|
Expand time |
≤10min |
|
Measurement and control radius |
30-50km |
